1, 2, 4, 6, or 8 port RJ-11 type Telephone POTS FXS/FXO & Ethernet 10/100 to Fiber Optic Converter

SKU:

AN-FM-PCM01-M (FXO)

Viết đánh giá

Nhận báo giá

ADD TO CART
- 0

MÔ TẢ
HƯỚNG DẪN MUA HÀNG

Nội dung bài viết [hide]

1 Tính năng
2 Thông số kỹ thuật
3 TELEPHONE PARAMETERS
4 Cài đặt
5 Thông tin sản phẩm

Tính năng

Low cost solution for delivering analogue POTS lines over long distance fibers;
up to 1, 2, 4, 6 or 8 FXO RJ-11 ports for connection to PABX or PSTN;
up to 1, 2, 4, 6 or 8 FXS RJ-11 ports for connection of phones or faxes;
Ethernet port for LAN interconnection along with voice ports over same fiber;
MTBF more than 10 years
WDM Bidi fiber interfaces available

Thông số kỹ thuật

TELEPHONE PARAMETERS

Physical interface: RJ11
Analog telephone / switch interface characteristics
Voice Bandwidth: 8KHZ
Codec method: PCM codec
Signaling Control: Transparent support any in-band signaling
Interface communication terminal: Ordinary telephone or group telephoon, program-controlled switches (PBX), public telephone network PSTN
Connection: Point to point link/PBX system
FXS: Ringing voltage: 75V, ringing frequency: 25HZ
FXO: Two-wire input impedance: 600Ω (off-hook)
Return loss: 40 db, ringing detection voltage: 35V
Ring detection frequency: 17HZ-60HZ, wire input impedance: 600Ω (off-hook),
Return loss: 40 db
Stand-alone or rack-mounted optional.
Can be inserted into our 18-slot, 19inch 4U
Rack-mountable chassis with redundant power

Optical interface

Optical wavelength: single mode 1310nm/1550nm
Fiber: single fiber or double fiber for option
Transmission range: 0-50Km/100Km for option
Optical interface: SC/FC/ST
Dimension:
(17.3*15*2.8cm for 1,2 and 4 port units
(17.3*15*4.5cm) for 6 and 8 port units

Ethernet interface:

Interface Rate: 10/100Mbps
Interface character: match IEEE802.3, IEEE802.1 Q
Connector: RJ45

Working condition

Voltage: AC220V; DC –48V; DC +24V
Consumption: ≤5W
Working temperature: 0°C~50°C
Storage temperature: -35°C~+70°C
Relative humidity: 95 %
PACKING LIST
Please check the following items in the package before installation.
1×Optical transmitter
1×Optical receiver
2×AC/DC power adaptors
1×User’s manual
1×Warranty card

Cài đặt

Thông tin sản phẩm

AN-FM-PCM01-M (FXO)	1 FXO channels Voice (1FXO) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM01-M (FXS)	1 FXS channels Voice (1FXS) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM01/ETH-M (FXO)	1 FXO channels Voice (1FXO)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM01/ETH-M (FXS)	1 FXS channels Voice (1FXS)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM02-M (FXO)	2 FXO channels Voice (2FXO) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM02-M (FXS)	2 FXS channels Voice (2FXS) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM02/ETH-M (FXO)	2 FXO channels Voice (2FXO)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM02/ETH-M (FXS)	2 FXS channels Voice (2FXS)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM02/ETH-M (FXO)	2 FXO channels Voice (2FXO)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 40Km (or more, depending on model, Multimode models also available)
AN-FM-PCM02/ETH-M (FXS)	2 FXS channels Voice (2FXS)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 40Km (or more, depending on model, Multimode models also available)
AN-FM-PCM04-M (FXO)	4 FXO channels Voice (4FXO) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM04-M (FXS)	4 FXS channels Voice (4FXS) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM04/ETH-M (FXO)	4 FXO channels Voice (4FXO)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM04/ETH-M (FXS)	4 FXS channels Voice (4FXS)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM06-M (FXO)	6 FXO channels Voice (8FXO) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM06-M (FXS)	6 FXS channels Voice (8FXS) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM06/ETH-M (FXO)	6 FXO channels Voice (8FXO)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM06/ETH-M (FXS)	6 FXS channels Voice (8FXS)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM08-M (FXO)	8 FXO channels Voice (8FXO) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM08-M (FXS)	8 FXS channels Voice (8FXS) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM08/ETH-M (FXO)	8 FXO channels Voice (8FXO)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
AN-FM-PCM08/ETH-M (FXS)	8 FXS channels Voice (8FXS)+ 1 Ethernet port (10/100M adapt) on fiber mux. Single mode single fiber 20Km (or more, depending on model, Multimode models also available)
